Description
1" FPT Locking Ball Valve 600 Wog Full Port On-Off Lock
Part number: 0826LH-10
Sold as: Pack of 8
Estimated shipping: 14+ days
Category: Valves
UPC: 777808245420
Specifications
- Product Family: Brass Ball Valves - Locking Handle
- Boshart Part Number: 0826LH-10
- Available In: 1"
- Carton Quantity: 8
- UPC: 777808245420
- Package Width: 2.9 in
- Package Height: 1.85 in
- Package Length: 6.6 in
- Package Weight: 1.35 lb
- Description: Note: Padlock not included.
- Ball Material: Chrome Plated
- Port Size: 0.98 INCH in
- Size: 1"
- Handle Type: Rubber Grip
- Design: Full Port
- Seat Material: PTFE
- Connection Type: FPT
- Primary Material: Brass
- Temperature Range: Up to 350°F (177°C)
- Maximum Pressure Rating: 600 PSI CWP
- Stem Packing Material: Viton
- Product Model Short Description: Brass Ball Valves - Locking Handle
- Certifications: ANSI Z21.15 & CGA 9.1: 1/2 PSIG (1/2 PSI) ASME B16.33 & CAN/CGA 3.16:125PSIG (BRS125G / CAN3.16) ASME B16.44 & CGA/CR91-002: 5 psig (5G) UL 1477 (YQNZ): Compressed gas shutoff valves - 600 PSI UL 258 (VQCU): Trim and drain valves - 600 PSI UL 842 (MHKZ): Manual valves - 600 PSI UL 842 (YRBX): Flammable liquid shutoff valves - 600 PSI UL 842 (YRPV): Gas shutoff valves - 600 PSI
